Cylinderical Mould

Cylindrical Mould

Standard: British & Indian
Use: Cylindrical Moulds are used to make concrete cylinders. These concrete cylinders are used for compressive strength tests.

Specification:

The Cylinderical mould is split vertically into two parts. The mean internal diameter is within ± 0.2 mm and height is within ± 1mm. The ends are machined to ± 0.05 mm. The base plate and top plate are machined flat to ± 0.03 mm.

Technical Specifications:
Product Code	Specifications	Size
ZI 2017	Mould Cylinder, Cast Iron	15 cm dia x 30 cm height
ZI 2018	Mould Cylinder, Cast Iron	6 cm dia x 32 cm height
ZI 2019	Mould Cylinder, Cast Iron	10 cm dia x 20 cm height
ZI 2020	Mould Cylinder, Cast Iron	30 cm dia x 60 cm height
